BLUETTI APEX 300 + B300K + 2 × 200W Solar Generator Kit

Whole-Home & RV Modular Battery Eco-System, 3,840W Split-Phase 120V/240V Inverter Station, High-Efficiency 400W Foldable Monocrystalline Solar Panel Bundle

Secure total energy independence, reliable home emergency readiness, or high-capacity off-grid RV utility with the BLUETTI APEX 300 + B300K + 2 × 200W Solar Generator Kit. This premium clean-energy ecosystem doubles your out-of-the-box runtime by pairing the next-generation APEX 300 master unit with a high-capacity B300K battery expansion block and two 200W folding monocrystalline solar panels. Delivering a massive 5,529.6Wh of combined storage capacity alongside a 400W solar generation grid, this plug-and-play platform gives you the standalone power to turn raw sunlight into clean electricity, running demanding 120V and 240V appliances simultaneously without noise, fuel storage logistics, or toxic emissions.

The power station's core inverter architecture is driven by a continuous 3,840W pure sine wave transformer that easily handles intense short-term startup surges up to 7,680W. Utilizing long-life, military-grade tested Lithium Iron Phosphate (LiFePO4) cells managed by an intelligent EnerBalance AI platform, the combined system delivers over 6,000 full power cycles—promising up to 17 years of dependable daily deployment. With a near-instantaneous 0ms UPS switchover circuit, critical home networking loops, deep freezers, and sensitive medical CPAP equipment stay powered seamlessly through unexpected storm blackouts.

Key Product Features & Core Engineering

• Simultaneous 120V & 240V Delivery: Native split-phase power architecture runs high-amperage appliances (well pumps, clothes dryers, mini-splits) and low-voltage delicate electronics at the same time.

• Massive 5.5kWh Expanded Battery Vault: Connects the core power station and B300K module together via a secure, heavy-duty link cable to supply long-term backup security that can scale modularly up to 58kWh.

• 400W High-Efficiency Solar Grid: Includes two premium 200W folding solar mats built with monocrystalline silicon cells and an advanced ETFE surface layer, achieving up to 23.4% conversion efficiency.

• 0ms Seamless UPS Switching: High-speed automatic backup line instantly shields data systems, storage arrays, and sensitive medical items from unexpected grid crashes.

• Smart AI Peak-Load Shifting: Easily customize daily scheduling via the BLUETTI smartphone app to recharge using solar or cheap off-peak utility pricing, then discharge during peak hours to lower your monthly bills.

• Rugged Military-Grade Frame Build: Fully certified and stress-tested to strict MIL-STD-810G structural parameters, complete with detachable dust filtration layers and space-saving modular lines.

Technical Specifications Summary

Comprehensive Product Packaging List

• 1 × BLUETTI APEX 300 Master Modular Power Station Unit (2,764.8Wh)

• 1 × BLUETTI B300K Deep-Cycle Expansion Battery Pack Module (2,764.8Wh)

• 1 × Heavy-Gauge Dedicated Locking Battery Interconnect Cable

• 2 × BLUETTI 200W Folding Monocrystalline Solar Panel Mats

• 1 × High-Amperage Standard Ground AC Wall Outlet Charging Cable

• 1 × Integrated MC4-to-XT60 20A Solar Connection Cable Array

• 1 × Universal Car Cigarette Accessory Socket Charging Adapter

• 1 × Master System Technical Blueprint, Panel Alignment Guide, and User Manuals

Critical Field Installation & Operational Guidelines

• Secure Interconnect Locking Routine: When linking the B300K expansion battery to the main APEX 300 power station, insert the heavy-gauge interconnect cable firmly until it seats completely into the bay, then engage the structural mechanical slider locks on the plug body. Never attempt to connect or detach this high-current cable while either unit is active.

• Solar Open-Circuit Voltage Bounds: The APEX 300 features dual internal MPPT charge controller lines, each accepting 12V to 60V DC up to 20A. Each 200W solar panel outputs an Open Circuit Voltage (OCV) of 24.6V. When wiring panels into individual MPPT ports, keep array boundaries well below the 60V max limit under cold weather conditions to prevent tripping the safety shut-offs.

• Sub-Zero Protection Protocols: Although the station's durable frame handles extreme environments, lithium iron phosphate cells cannot safely accept a high charge current if internal cell temperatures drop below freezing (32°F or 0°C). During winter use, ensure the APEX 300 and B300K remain inside an insulated cabin, tent, or vehicle compartment to let the cells recharge safely.
